Nyhet!

OCTAVE JUBILEE 300 B

830 990,-
FRI FRAKT

Ta kontakt for pris og konfigurasjon

Send epost
Finnes i flere varianter!

OCTAVE JUBILEE 300 B

Octaves kreative løsning på klasse A uten begrensninger!

Octave's objective was to develop a 300B amplifier that provides enough power for most speakers, while not interfering with the classic 300B circuit. It was not about power for the sake of power, but about providing the 300B with a perfect environment that enhances the tonal qualities of this tube.

The concept of a 300B single-ended amplifier delivering 20-30W output power with three power tubes in indirect parallel operation was thus born.

There is a fundamental problem regarding "direct" heating of the triodes:

Unlike indirectly heated tubes (such as the KT88, KT120, etc.), directly heated triodes cannot operate directly in parallel because of the complex demands on the heating system needed increase output power.

The typical 50 Hz AC heater voltage would cause unacceptably high hum and power disturbances in the speaker. Although DC heating eliminates the hum, it also limits the sonic potential of the 300B.

Octave's solution:

They have developed a 7 Hz power generator that supplies each of the three 300B tubes with a separate, regulated 7 Hz pure sine wave heating voltage.

• This makes it possible to connect several 300B tubes in parallel.

• Sound-affecting ripple and RF disturbances of the line frequency are completely eliminated.

• Heating and operating voltage are electronically controlled, sound instabilities due the fluctuating mains voltage is a thing of the past.

• Only then can the tonal potential of the 300B be fully exploited. The 300B tubes will now operate in the optimised region and can fully develop their tonal qualities. Now it becomes clear why she is called the "queen" of tubes.

Thus, the Octave Jubilee 300 B is an absolutely modern and uncompromising implementation of arguably the finest amplification technology in the high-end sector. The amp offers an emotional, smooth, high resolution, dynamic and expansive triode sound, not only in the mid/high frequency range, but for the first time, completely across the full audio band.

Tekniske data

Output Power between 15 and 30 W selectable
Power bandwidth 20 Hz - 50 kHz / - 3 dB
Gain low 19,5 db @ 4 Ohm; 22,5 dB @ 8 Ohm
Gain high 30 dB @ 4 Ohm; 33 dB @ 8 Ohm
Signal to Noise Ratio @ 20W Gain high > 100 dB; Gain low > 110 dB
Damping factor 4,5
Input Sensitivity Gain high 0,5 V; Gain low 1,7V
Connections 1 x Cinch, 1 x XLR Input
4 and 8 Ohm Loudspeaker Outputs
Power Consumption 400 Watt at full power
Weight 60 kg each Amplifier
Standard Accessory Power cord, Screwdriver
Dimensions H x W x D = 660 mm x 240 mm x 400 mm
